Microplate Absorbance Reader


Filter based system with wavelength range from 340-750nm; 0.0 to 4.0000 Abs absorbance range; 8 channel vertical optical path with zero dispersion; Integrated, multispeed plate shaker. Use as stand alone with 7" color touch screen or connect a mouse for programming and operation. Menu interface allows user to choose wavelength filter, set shaking parameters (slow, medium or fast), enter details of plate layout and choose details for reading protocol and data calculations. Includes four filters: 405, 450, 492, 630nm with 26 additional filters available separately to cover a full range from 340 to 750nm. Integrated filter wheel allows up to 8 filters to be loaded at once. Filters can be selected during programming. Up to two filters can be used for two measurements of sample plate for calculated comparisons. Kinetic calculations can be performed by setting multiple readings. Specifications: Read-out Range: 0~4.000 Abs; Linearity: 0~1.000 Abs <+1%; 2~4.000 Abs <+2%; Test Speed: <6 seconds for 96 well plate; Storage: 200 programs and 100,000 test records; Dimensions: 11.6" x 17" x 8.75"/295mm x 440mm x 225mm
